دوربین نقشه برداری Leica TS03

Accuracy Hz and V

Absolute, continuous, diametrical  ……………………………. 2’’ / 3’’ / 5’’

Display resolution: 0.1’’ (0.1 mgon)
Quadruple axis compensation
Compensator setting accuracy2: 0.5’’ / 1’’/ 1.5’’ / 2’’
Compensator range: +/- 3.78’ (+/- 0.07 gon)
Electronic level resolution: 2“
Circular level sensitivity: 6` / 2 mm

DISTANCE MEASUREMENT

Range:

Prism (GPR1, GPH1P): 1.5 m to 3.500 km
Prism GPR1 (Long Range mode) > 10.000 km

Non-Prism / Any surface:

R5003………………………………………………………………….. ✔
R1000 ………………………………………………………………….  ✗

Single prism

Precise+ / Once: 1 mm + 1.5 ppm (typical 2.4 s)
Precise&Fast / Once&Fast: 2 mm + 1.5 ppm (typical 2 s)
Tracking / Continously: 3 mm + 1.5 ppm (typical < 0.15 s)
Averaging: 1 mm + 1.5 ppm
Long Range mode / > 4 km: 5 mm + 2 ppm (typical 2.5 s)

Laser dot size

Non-Prism / Any surface

0 m – 500 m: 2 mm + 2 ppm (typical 3 – 6 s)
> 500 m: 4 mm + 2 ppm (typical 3 – 6 s)
At 30 m: 7 mm x 10 mm
At 50 m: 8 mm x 20 mm
At 100 m: 16 mm x 25 mm

Telescope

Magnification: 30x
Resolving power: 3”
Focusing range: 1.55 m / 5.08 ft to infinity
Field of view: 1°30’ / 1.66 gon / 2.7 m at 100 m

Display and keyboard

3.5“ (inch), 320 x 240 px QVGA, grayscale, 28 keys5a

2nd keyboard…………………………………………………….✗

Key illumination  ………………………………………………. ✗

Operation

Endless drives for HZ & V……………………………………..  ✔
Trigger-Key: user definable with 2 functions……………….✔

Power management

Exchangeable Lithium-Ion battery

Operating time with GEB361 ………………………… up to 30 h
nn Operating time with GEB331…………………….. up to 15 h

Battery charging time with

GKL341 charger for GEB361 / GEB331 …………………….3 h 30 min / 3 h
nn GKL311 charger for GEB361 / GEB331………………….6 h 30 min / 3 h 30 min

External supply voltage

Nominal voltage 13.0 V DC & 16 W max……………………. ✔

Data storage

Internal memory: 2 GB Flash ……………………………………..✔
Memory card: SD card 1 GB or 8 GB  ……………………………✔
USB memory stick: 1 GB …………………………………………..✔

Processor

TI OMAP4430 1GHz Dual-core ARM  Cortex  A9 MPCore……✔
Operating system – Windows EC7 ……………………………..✔

Interfaces

RS2327, USB device ………………………………………………..✔

Bluetooth  , WLAN  …………………………………………………..✗
Mobile Data sidecover: LTE-Modem for internet access ……..✗

Guide Light (EGL)
Working range: 5 m to 150 m…………………………………………✗
Position accuracy: 5 cm at 100 m……………………………………✗
Wavelength red /orange: 617 nm / 593 nm……………………..✗

Laser plummet (Laserclass 2)

Accuracy:

Plumb line deviation: 1.5 mm at 1.5 m instrument height……….✔
Diameter of laser point: 2.5 mm at 1.5 m instrument height……..✔

AutoHeight module for automatic instrument height measurement (Laserclass 2)

Accuracy:

Distance accuracy: 1.0 mm @ 1 m …………………………………✗
nn Distance range: 0.7 m to 2.7 m………………………………….✗

Weight …………………………………………………………..4.3 kg

Environmental specifications

Working temperature range: –20°C to +50°C…………………….✔
Arctic version: –35°C to +50°C ……………………………………….✗
Dust / Water (IEC 60529) / Humidity: IP66 / 95%, non-condensing…………✔
Military Standard 810G, Method 506.5……………………………✔

✔ = Included                      • = Optional                                ✗ = Not available
